5-Gallon Cap Sealing Machine
This machine seals film onto 5-gallon water bottle caps.
Caps are sorted and fed automatically, placed by vacuum, then the film is fed, cut and sealed on, with a second sealing pass before the finished caps are counted.
The standard model runs 2,400 caps per hour on two stations. Send your cap drawing or photos, and we'll tell you whether it fits.
Overview
Key Points
- Automatic cap sorting and feeding
- Film fed, cut and sealed onto each cap, then a second sealing pass
- Finished caps counted at the outlet
- 2,400 caps per hour on two stations (standard model)
Key Figures
Typical specifications
| Item | Value |
|---|---|
| Output | 2,400 per hour (two stations) |
| Installed power | 1.8 kW |
| Power supply | 380 V |
| Max air consumption | 0.5 m³/min |
| Warranty | 2 years on mechanical parts, 1 year on electrical parts (faults not caused by misuse) |
Final configuration is matched to your part and output.
What It Runs
Suitable Parts
5-gallon water bottle caps.
Answers
Frequently Asked Questions
The standard model runs 2,400 caps per hour on two stations. Your machine is set up for your own cap, so the final figure comes with your quote.
It depends on the part, the number of steps and the output you need. Send us those details, and we'll send an exact quote within 24–48 hours.
The standard model runs 2,400 caps per hour on two stations: caps are sorted and fed automatically and placed by vacuum, then the film is fed, cut and sealed on, with a second sealing pass before the finished caps are counted. Send your cap drawing and we'll tell you whether it fits.
The 5-gallon cap sealing machine runs on 380 V with 1.8 kW installed power and up to 0.5 m³/min of air. It seals film onto the cap; the 5-Gallon Cap Assembly Machine instead fits the plug into the cap. Tell us which step you need.
We supply two: the 5-Gallon Cap Sealing Machine on this page, which seals film onto the cap at 2,400 caps per hour on two stations, and the 5-Gallon Cap Assembly Machine, which fits the plug into the cap at 5,000 per hour. Tell us which step you need and send your cap drawing.
We install and commission the machine at your plant and train your team there. The warranty is 2 years on mechanical parts and 1 year on electrical parts, for faults not caused by misuse. Spare and wear parts for the machines we supply come through us, so after-sales is one contact.
Get a Quote
Request a Quote for This Machine
Send us your part drawing or photos. We check which machine fits, then send you a quote.
