Switch & Junction Box Assembly Machines
Grippers assemble switch modules on a rotary table, then fit each one into its frame.
Our switch and junction box assembly machines cover three jobs: putting wall switches together, fitting the small parts into electrical junction boxes, and driving the screws that hold a part together. Each machine is set up for your own parts.
Machines for wall switches, junction boxes and screw tightening
Wall Switch Assembly Machine
Puts the seven parts of a wall switch together on a rotary table, then presses each switch into its frame.
- About 1,200 pcs/hour (typical)
Junction Box Assembly Machine
Assembles five-part junction boxes: a belt brings the boxes in, two vibratory bowls feed the small parts.
- About 15–25 pcs/min (typical)
Automatic Screw Tightening & Fastening Machine
An electric screwdriver on a benchtop gantry drives each screw into a part held in a fixture.
- About 1.5–3 seconds per screw (typical)
Which machine fits your part?
Start with the job you want to automate.
| You need | Machine |
|---|---|
| Wall switches | Wall Switch Assembly Machine Grippers set the seven switch parts into fixtures on a rotary table, and a pressing station fits each switch into its frame, with a vibratory bowl feeding the small parts. A typical machine runs about 1,200 switches per hour; send us your parts and we'll tell you how fast yours can run. |
| Electrical junction boxes | Junction Box Assembly Machine The boxes ride a belt through the stations while two vibratory bowls feed the small parts into each box. We supplied a line for five-part junction boxes to a customer in Bangladesh; a typical machine runs about 15–25 boxes per minute. |
| Driving the screws into a part | Automatic Screw Tightening & Fastening Machine A benchtop machine: the part sits in a fixture, and an electric screwdriver on a gantry moves from hole to hole, driving one screw after another, typically in about 1.5–3 seconds per screw. Send us your part and show us where the screws go. |
Every machine is set up for your own parts, so the figures above are typical and the speed for your part is confirmed before you order. For other household, stationery and automotive parts, see our household and electrical parts assembly machines.
Frequently Asked Questions
Send us your switch or junction box parts
Drawings or photos of each part and the assembled switch or box, plus your target output. We'll tell you whether it can be assembled by machine, and how fast. Get an exact quote within 24–48 hours.
