Pen Writing Test Machine
Under red light, a row of pressing heads holds the pens in place as they move through the test stations.
This machine checks refills and finished pens by drawing a test line with each one.
We have supplied writing test machines to pen makers in Bangladesh, for refills and finished pens, and in Pakistan, combined with tip cleaning or wax tipping on the same machine.
Every machine is set up for the customer's own parts. Send photos or drawings of each part and the finished pen, and we'll tell you whether it fits.
Used for: Highlighter & marker making machines Pen refill making machines
Key Points
- 260–320 refills per minute, twenty at a time (standard model)
- Can be combined with tip cleaning or wax tipping on one machine
- Set up for your own pen parts
Typical specifications
| Item | Value |
|---|---|
| Refill writing test | 260–320 per minute, 20 at a time; 6800 × 1000 × 1670 mm |
| Finished pen writing test | 150–180 per minute, 10 at a time; 7100 × 1500 × 1800 mm |
| Warranty | 2 years on mechanical parts, 1 year on electrical parts (faults not caused by misuse) |
Final configuration is matched to your part and output.
Suitable Parts
Pen refills and finished pens.
Frequently Asked Questions
How it is assembled: How a Ballpoint Pen Is Assembled by Machine
Request a Quote for This Machine
Send us your part drawing or photos. We check which machine can assemble it, then send you a quote.
